FAX

Fax Compatibility

Group III, CCITT

Fax Modem

Built-in Class 2 Fax Modem via parallel port

Modem speed

9600 bps (bits per second)

Buffer memory

256KB memory

Compression schemes

MH, MR, MMR, with ECM (Error Correction Model)

Memory upgrade Module

Available in 1 MB

Advance fax features

Automatic redialing, Broadcasting faxing, Coded speed dialing:152 locations scheduled transmission up to 24 hours in advance, Polled transmissions or reception

Management reports

LM200 system status report, Transaction report, Phone book listing

Scanner

Scan type

CCD

Resolution

204 x 98 dpi Standard, 204 x 196 dpi ,204 x 392 dpi Super Fine

Software interface

TWAIN driver using TIFF format; compatible with most OCR packages and image editors

Image quality

Scan in Bi-level or halftones or phonos

Copier

Operation

Quick copy, multiple copies, or collated copies

Resolution and speed

Printer dependent

Scaling

25% to 250% of the original size

PC Fax

Operation

Send single faxes or broadcast faxes, Forwards faxes to another recipient,  Mixes pages from Windows application, Stores and saves with 50 character index

Cover Sheet

Includes choice of 5 cover sheets, Enables paste-in of company logo

General

Automatic document feed

Up to 30 sheet capacity

Display

2 x 20 line LCD

Keyboard

Full set of alpha-numeric keys

Document sizes

Width: 5 inches to 11 inches                  Length: 5 inches to 16.5 inches

Printer Support

Most inkjet and laser printer with HP, Proprinter, Bubblejet, PostScript, and Epson emulations

LM200 control panel

Windows-Based interface which allows all features to be operated from a PC

Telephone

Optional handset available

Telephone answering machine

Connector for telephone answering machine with automatic voice/fax detection

Power requirements

90 vac to 240 vac; 47 Hz to 64 Hz

Dimensions

7”H x 15” x 7”D

Weight

Approximately 4 LB

Safety standards

FCC part 15 Class B and Part 68, UL-1950, CSA, DOC

Installation Requirements

Computer

IBM Computer PC 80386 or higher with 4 MB RAM running Windows

Printer

Inkjet, 24-wire dot-matrix, or laser

Phone Line

Phone line with RJ11 connector
